Fosi ZD3 DAC Pre-Amp with remote

$449.00

Fosi Audio’s ZD3 is a balanced DAC with excellent connectivity thanks to its multiple inputs and Bluetooth 5.0 chip. The digital/analogue conversion is based on an ES9039Q2M chip, which supports PCM up to 32bit 768kHz and DSD up to DSD512. Three DIP8-mounted OPAs can also be replaced if you wish to have a different tone.

In stock

Hi there! How can we be of assistance?



Fosi Audio ZD3 Bluetooth Desktop DAC Preamplifier

Fully Balanced Design

Fosi Audio ZD3 Flagship Desktop DAC Preamplifier

Presents tailored DAC performance, ensuring superior audio quality for pure enjoyment with ease of use.

Fosi Audio ZD3 Bluetooth Desktop DAC Preamplifier

High-Performance Digital-to-Analog Audio Converter

The ZD3 is a audiophile-grade balanced stereo DAC meticulously developed by Fosi Audio after thoroughly understanding user needs. It features the ES9039Q2M high-precision DAC chip, delivering rich and superior sound.

  • Input: USB, HDMI ARC, Optical, Coaxial, Bluetooth
  • Output: XLR, RCA; Power Supply: 12V 1.5A
  • SNR≥126dB; THD+N<0.00008%
  • Bluetooth Codecs: SBC, AAC, aptX, aptX HD



Fosi Audio ZD3 Bluetooth Desktop DAC Preamplifier

Swappable Op-Amp Design

Easily replaceable DIP8 dual discrete op-amps, meeting your pursuit of a personalized audio experience, such as LME49720, NE5532, MUSES02, SS3602.

Fosi Audio ZD3 Bluetooth Desktop DAC Preamplifier

Perfect Match to ZA3 Amp

In the same series and form factor, the ZD3 provides seamless integration with the ZA3, unlocking audio details and clarity.

Fosi Audio ZD3 Bluetooth Desktop DAC Preamplifier

Trigger In/Out

It enables synchronized switching of audio settings and automatic system control for seamless operation.

Fosi Audio ZD3 Bluetooth Desktop DAC Preamplifier

Bypass Mode

The signal bypasses the internal preamp section, providing a fixed output level for direct signal transmission.

  • Flagship Desktop DAC: A fully balanced digital-to-analog converter preamp with multiple inputs and outputs. Fosi Audio’s first DAC to support HDMI ARC input and comes equipped with a high-performance ES9039Q2M chip to deliver rich and superior sound.
  • Premium Chipset: The ZD3 features the chipset consisting of XMOS XU316+ES9039Q2M+QCC3031+LME49720. It supports high audio resolution, with a maximum capability of DSD512 and PCM 32bit/768kHz sampling rates, providing unparalleled clarity and depth.
  • Versatile & Flexible: The ZD3 offers comprehensive connectivity, supporting inputs like Bluetooth, USB, OPT, COAX, HDMI ARC, and balanced XLR/RCA outputs. This flexibility allows you to customize your audio system to suit various setups and scenarios.
  • Ease of Use: The ZD3 adopts a 1.5-inch OLED display, remote control, preamp bypass switch, and 12V trigger in/out interfaces, allowing synchronized power on/off with other home audio devices, all for a good user experience.
  • Family Design: Featuring the same design language as the ZA3 amplifier: compact and exquisite appearance and audiophile-grade components for high performance and excellent sound quality. Pair it with the ZA3 to create a robust home audio system.

Product type DAC
DAC chip ES9039Q2M
OPA LME49720
Inputs 1x USB-B, 1x HDMI ARC (CEC compatible), 1x Coaxial, 1x Optical Toslink, Bluetooth
Outputs 1x Stereo XLR, 1x Stereo RCA
Supported Sampling Rates USB : PCM 32bit 768kHz / DSD512
Optical/Coaxial/HDMI : PCM 24bit 192kHz
Bluetooth : PCM 24bit 48kHz
Output Level XLR: 5Vrms, RCA: 2.5Vrms
SNR 126dB
SINAD ≥ 120dB
THD+N < 0.00008%
Dynamic range ≥ 123dB
Noise level ≤ 2μV
Bluetooth version 5.0
Bluetooth operating range ≥ 13m
Supported codecs aptX HD, aptX, AAC, SBC
USB compatibility Windows 7, 8, 8.1, 10, 11 (driver required), Mac OS X, Linux
Power supply DC 12V 1.5A
Color Black
