“Sit anywhere” Uni-Q sound
At the heart of the evolved Q Series is the Uni-Q driver array. The signature innovation places the tweeter in the acoustic centre of the midrange and bass cone, bringing the acoustic ideal of a single point source closer than ever to realisation. The result is a more detailed, accurate three-dimensional sound image, which is dispersed more evenly throughout the room than is possible with any conventional speaker. Uni-Q’s ultra-wide dispersion is further enhanced through KEF’s ‘tangerine’ waveguide over the tweeter dome.
New system design
To optimise the high-resolution purity of the Q Series bookshelf speakers, the Uni-Q driver is repositioned to the center of the cabinet to reduce unwanted internal resonance and adding refinement to sonic clarity and detail. With the addition of the damped tweeter loading tube providing a gentle termination of sound produced from the back of the tweeter, lower treble performance is improved dramatically and a new low-distortion inductor on the crossover provides cleaner bass.
CFD-designed port
Featuring a Computational Fluid Dynamics (CFD) port design with the port repositioned to the rear of the speaker, clarity is improved by reducing the audibility of the midrange leakage through the port.
CFD-designed port
Featuring a Computational Fluid Dynamics (CFD) port design with the port repositioned to the rear of the speaker, clarity is improved by reducing the audibility of the midrange leakage through the port.
New system design
To optimise the high-resolution purity of the Q Series bookshelf speakers, the Uni-Q driver is repositioned to the center of the cabinet to reduce unwanted internal resonance and adding refinement to sonic clarity and detail. With the addition of the damped tweeter loading tube providing a gentle termination of sound produced from the back of the tweeter, lower treble performance is improved dramatically and a new low-distortion inductor on the crossover provides cleaner bass.
“Sit anywhere” Uni-Q sound
At the heart of the evolved Q Series is the Uni-Q driver array. The signature innovation places the tweeter in the acoustic centre of the midrange and bass cone, bringing the acoustic ideal of a single point source closer than ever to realisation. The result is a more detailed, accurate three-dimensional sound image, which is dispersed more evenly throughout the room than is possible with any conventional speaker. Uni-Q’s ultra-wide dispersion is further enhanced through KEF’s ‘tangerine’ waveguide over the tweeter dome.
Design Two-way bass reflex
Drive Units 165mm (6.5in.) aluminium Uni-Q 25mm (1in.)vented aluminium dome HF
Frequency range free field 42Hz (-6dB)
Frequency Response 63Hz-28kHz (±3dB)
Crossover Frequencies 2.5kHz
Maximum Output 110dB
Amplifier requirements 15-120W
Sensitivity 87dB (2.83V/1m)
Nominal Impedance 8 Ohms (min.3.7 Ohms)
Dimensions (H x W x D) 358 x 210 x 306 mm
Weight 7.6kg
