DESIGN
Two-way closed box
DIMENSIONS
(H x W x D)
330*x 140 x 35mm(13.0 x 5.5 x 1.4 in.)
330*x 140 x 35mm(13.0 x 5.5 x 1.4 in.)
center mode (H x W x D) :
140 x 330 x 35mm(5.5 x 13.0 x 1.4 in.)
WEIGHT
1kg (2.2lbs)
DRIVE UNITS
115mm (4.5in.) dual layer MF
25mm (1in.) aluminium HF
25mm (1in.) aluminium HF
FREQUENCY RESPONSE
80Hz – 30kHz
CROSSOVER FREQUENCIES
1.7kHz
AMPLIFIER REQUIREMENTS
10 – 100 W
SENSITIVITY
(2.83V/1m)
90dB (wall mount)
87dB (floor stand mount)
90dB (wall mount)
87dB (floor stand mount)
IMPEDANCE
8 Ohms
INTERNAL VOLUME
0.7 Litres
MAXIMUM OUTPUT
107dB (SPL)
REMARKS
* Height of satellites will increase by 30mm when using supplied desk stand. Not all models / finishes are available in all markets. Contact your local dealer for specific range details.
