Nagaoka JT-80BK (Black) High Output MM Cartridge

$999.00

Nagaoka JT-80BK High Output MM Cartridge

Available On backorder

Jeweltone MM Cartridge

Nagaoka JT80BK Phono Cartridge

The Nagaoka JT80BK uses a boron cantilever for outstanding stiffness and light weight. A solid elliptical needle brings delicacy in the high range and good sound balance from the low range.
Nagaoka is a formidable name in the world of phono cartridges.

In fact, Nagaoka styli are still used by many world renowned companies under their private label. The company offers an impressive range across budget lines for every need. The precision craftsmanship and stringent quality control sets Nagaoka apart from all of its competitors.

Type: Moving Magnet

Cantilever: Boron

Stylus type: 0.4×0.7mm Ellipse / Diamond

Output voltage: 3 mV (5cm/sec)

Frequency characteristic: 20 – 20,000 Hz

Channel balance: 1dB or less

Channel separation: 25 dB at 1 kHz

Recommended loading: 47,000 ohms

Dynamic Compliance: 7.3 x 10-6 cm/dyne

Tracking force range: 1.3 – 1.8 g
