Silent Angel Rhein Z1 Plus $5,999.00 – $10,999.00

Silent Angel Rhein Z1

$3,799.00

Rhein Z1

Your Center of Digital Music, An Audiophile’s Ultimate Dream

High-performance music server with an advanced hardware mainboard, high-quality CNC aluminum alloy chassis, and optimized music server OS & software giving the pleasant user experience. Z1 is the ideal digital music center for your home audio network, as well as a solid computing node to serve versatile streaming services. Enjoy superior sound quality through your HiFi system.

Hi there! How can we be of assistance?

Easy to Use, Pleasant User Experience

  • Stay connected to digital music – Play and enjoy anytime
  • Master your music server at your fingertips via mobile app, VitOS Manager
  • Install and enjoy various applications seamlessly
  • Essential core audio network to maximize your HiFi system’s sound performance

Mechanical Stability and Craftsmanship

Z1 is housed in the highest-grade CNC aluminum alloy chassis. Robust, vibration- and dust- free. No more excessive heat. Fanless, well-structured internal design provides efficient heat dissipation to keep the CPU and entire system running cool, but with zero fan-noise and extremely low electrical noise. A high permeability EMI absorber (> 120 @1MHz) is applied to reduce the noise from internal digital circuits including DRAM, CPU, etc.

Superior Hardware System and Mainboard

Z1 is born to pursue enhanced audio performance without any compromise.

  • High-performance yet low-power (6W) Intel CPU.
  • Advanced circuitry with high quality components.
  • Audio-grade SSD for system and music data storage. Noise-reduction via SATA signal optimization. Special-picked SSD modules with EMI absorber and special power regulation circuit inside to isolate the power noise from the SSD controller chip.

Mobile App, VitOS Manager

  • Discover and configure the network settings of Z1 Plus.
  • Install and manage add-on packages on VitOS, including Roon Server (Roon Core and Roon Bridge), Spotify Connect, DLNA renderer & server, Orbiter Plug-in,… etc. on Z1 Plus.
  • Import the music files from a USB hard drive to Z1 Plus’s internal disk with the Music Importer feature.
  • Back up the stored music files to an external USB hard drive with the Music Backup feature.
  • Firmware update.

Z1 as Your Music Server

Use Z1 as a center of digital music to serve multiple players.

  • Roon Core
  • Shared storage of music files (over SMB/CIFS)
  • DLNA server

Z1 as a Transporter and a Roon Bridge

Connect Z1 to your DAC(Digital to Analog Converter) via USB connection, it will stream and output the digital signals including PCM, Native DSD(up to DSD256) or DoP(up to DSD64).

It supports several infrastructures:

  • Transporter
  • Roon Bridge
  • DLNA renderer (player)
1 x 100 / 1000 base-T GbE with link / speed indicator
1 x USB audio (supplies 5VDC @ 0.5A at max)
2 x USB 2.0 (supplies 5VDC @ 0.5A at max)
1 x USB 3.0 (supplies 5VDC @ 2A at max)
1 x HDMI 1.4
Power Button Aluminum alloy material
Power Indicator Blue light
System Disk 120GB Silent Angel customized SSD
Storage Disk 1TB or 2TB Silent Angel customized SSD (optional)
System OS VitOS
CPU Power Consumption 6 Watt
SSD Power Consumption 60 mWatt at max
EMI Absorber Silent Angel Noise Absorber (SANA)
Power Adaptor 12VDC 7A switching power adaptor
Chassis Material 6061 aluminum alloy (at least 8mm thickness) chassis
Input Power External power 12VDC at 2A at max. *
Power Consumption 24W at max. **
Dimension 7.87(W) inch x 2.56(H) inch x 7.87(D) inch
200(W) mm x 65(H) mm x 200(D) mm
Weight 14.22 lbs / 6.45kg (gross weight)
Temperature Operating: 32 ~ 86 °F (0 ~ 35 °C)
Storage: -4 ~ 158 °F (-20 ~ 70 °C)
Humidity Operating: 10% ~ 90% RH (non-condensing)
Storage: 5% ~ 95% RH (non-condensing
Certificate CE, FCC
