The new Wharfedale SUPER LINTON represents a significant milestone in innovation for Wharfedale, being a standout addition to the globally best-selling Heritage series.
This updated model is part of a line of award-winning speakers that are renowned for their exceptional musicality and have won the hearts of tens of thousands of music lovers. Led by Peter Comeau, the Director of Acoustic Design, Wharfedale’s engineers revisited every aspect of the speaker’s design, including the cabinet, drive units, and crossover. The outcome of their efforts is the newly upgraded Super Linton.
The current iteration of the Wharfedale LINTON was launched in 2019 and has since become one of the company’s most successful loudspeakers… ever! Not only in the number of pairs sold but also in terms of awards, accolades and endorsements from enthusiasts and press alike.
As part of Wharfedale’s world-famous heritage series, LINTON can boldly but confidently claim to be one of the most astounding value loudspeakers of recent times.
Not only is LINTON an exception in design, build, and styling, but its industrial design and acoustic performance have been universally welcomed as a loudspeaker that brings musicality back to music and romance back to home hi-fi.
Still going strong and one of the most sought-after loudspeakers in the market, LINTON is going nowhere soon and remains a jewel in the crown of Wharfedale’s ever-popular Heritage series.
Unlike the SUPER LINTON of ’67, which was’ Super’ on the basis of mainly improved cabinet design, the new SUPER LINTON is genuinely SUPER in every way. Not detracting from its sister, the current LINTON, the SUPER LINTON takes one step further in engineering and performance in almost every aspect. The result is a moderately more expensive but extensively more capable loudspeaker that forms the perfect addition to the Heritage series, offering an upgrade path for existing LINTON owners but also bridging the gap between the flagship, made in the UK DOVEDALE model.
Like the original ‘Super’ concept, the new SUPER LINTON benefits from an enlarged cabinet and propriety Wharfedale sandwich cabinet design that features a resonance-reducing combination of two layers of MDF complemented with a layer of acoustic damping glue.
A new bass unit and a more powerful motor system enhance the low-frequency performance, extending down to 32Hz! This results in a more dramatic and impactful low-end.
For the treble output, SUPER LINTON features a lightweight fabric weave dome coated with special damp-ing material and supported by a ceramic magnet motor system, contributing to its sweet and detailed char-acter. The revised short horn profile ensures smooth response down to the upper midrange, and the new front plate design enhances high-frequency dispersion, matching the transient impact and detailing of the new bass unit.
A new revised chamber for the midrange drive unit works to cancel out mid-band specific back waves by multiple layers of long-hair fibre, resulting in a more natural prominence of the vocal and instrument frequencies.
General description
3-way vented-box / standmount
Design philosophy and core technology
Enclosure type
Bass Reflex
Transducer complement
3-way
ABR
–
Bass driver
8″(200mm) Black Woven Kevlar Cone
Midrange driver
5″(135mm) Black Woven Kevlar Cone
Treble driver
1″(25mm) Soft Dome
Sensitivity (2.83V @ 1m)
90dB
Recommended amplifier power
25 – 200W
Peak SPL
110dB
Nominal impedance
6Ω (Compatible 8Ω)
Minimum impedance
3.9Ω
Frequency response(+/-3dB)
39Hz – 20kHz
Bass extension(-6dB)
32Hz
Crossover frequency
550Hz & 2.5kHz
Cabinet Volume (in litres)
6.6L, 33.4L
Dimensions (mm)
–
Height (on plinth)
605mm
Width
300mm
Depth (with terminals)
(330+20)mm
Carton size
465 x 435 x 740mm
Net weight
19.8kg / pcs
Gross weight
22kg / ctn
